• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Datum Diameter (B)	15.4
Overall Length (in)	3.171875 in
Pitch Diameter (A)	15.2
Bushing Used	R1
Pulley Material	Cast Iron
Outside Diameter (in)	15.75 in
Datum Diameter (A)	15
Number of Grooves	2
Pitch Diameter (B)	15.7
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Face Width (in)	1.75
Bushing Bore Range	1.125 - 3.750
Overall Width (in)	3.15625
Keyway Size	.750

General Specifications

UPC	662289295104
Weight	31.35 LB
Packaged Length	15.75 IN
Packaged Width	15.75 IN
Packaged Height	1.75 IN
