• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	11.35 in
Datum Diameter (A)	10.6
Pitch Diameter (B)	11.3
Pulley Material	Cast Iron
Pitch Diameter (A)	10.8
Bushing Used	SK
Model Name	2AB_LG_Sheavemaster
Number of Grooves	2
Material	Cast Iron
Datum Diameter (B)	11
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Number of Hubs	1
Bore Type	QD Bushed
Bushing Bore Range	.500 - 2.625
Face Width (in)	1.75
Pulley Construction	Spoke
Overall Width (in)	2.09375

General Specifications

UPC	662289362967
Weight	17.64 LB
Packaged Length	11.38 IN
Packaged Width	11.38 IN
Packaged Height	1.75 IN
