• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Type of Bore	Bushed
Number of Grooves	2
Datum Diameter (A)	4.2
Pitch Diameter (A)	4.4
Model Name	2AKH_Sheave_Master
Pitch Diameter (3L)	3.86
Belt Section	4L or A, 3L
Bore (Min) (in)	0.375 in
Outside Length (in)	1.5 in
Outside Diameter (in)	4.45 in
Product Type	FHP - Bushed
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Bushing Bore Range	0.375 - 1.500
Face Width (in)	1.375
Overall Width (in)	1.5

General Specifications

UPC	662289212521
Weight	2.72 LB
Packaged Length	4.70 IN
Packaged Width	4.90 IN
Packaged Height	1.50 IN
HTC	8483.50.9040
Country of Origin	Mexico
