• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Material	Cast Iron
Datum Diameter (A)	11
Model Name	2AKH_Sheave_Master
Pitch Diameter (3L)	10.66
Type of Bore	Bushed
Pitch Diameter (A)	11.2
Product Type	FHP - Bushed
Bore (Min) (in)	0.375 in
Outside Length (in)	1.5 in
Outside Diameter (in)	11.25 in
Belt Section	4L or A, 3L
Bore Type	Split Taper Bushed
Bushing Bore Range	0.375 - 1.500
Overall Width (in)	1.5
Face Width (in)	1.375
Pulley Construction	Plain

General Specifications

UPC	662289142651
Weight	9.41 LB
Packaged Length	11.70 IN
Packaged Width	11.60 IN
Packaged Height	2.00 IN
HTC	8483.50.9040
Country of Origin	Mexico
