• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	28
Product Type	Gearbelt Pulley
Width (mm)	50.8 mm
Bore Range	1 1/8 to 3 3/4
Material	Steel
Bore Type	Bushed Bore
Belt Section	XH
Flange (in)	8.3750 in
Inside Diameter (in)	5.9375 in
Outside Diameter (mm)	195.3006 mm
Outside Diameter (in)	7.689 in
Width (in)	2 in
Pitch Diameter (in)	7.799 in
Face Width	2.5625
Overall Length (in)	3.15625 in
Pulley Construction	Solid
Length Through Bore	2.875
Hub Diameter (in)	5.375 in
Hub Projection	0.59375
Number of Hubs	1
With Flanges	With Flanges

General Specifications

UPC	662289114382
Weight	21.11 LB
Packaged Length	9.20 IN
Packaged Width	9.20 IN
Packaged Height	4.60 IN
HTC	8483.50.9080
Country of Origin	United States of America
