• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Width (mm)	25.4 mm
Model Name	GBPulley_Master5
Number of teeth	28
Bore Range	1/2 to 1 3/4
Bore Type	Bushed Bore
Material	Ductile Iron
Belt Section	H
Width (in)	1 in
Pitch Diameter (in)	4.456 in
Outside Diameter (mm)	111.8108 mm
Outside Diameter (in)	4.402 in
Flange (in)	4.687 in
Face Width	1.3125
Overall Length (in)	2.219 in
Hub Projection	0.875
Hub Diameter (in)	3 in
With Flanges	With Flanges
Number of Hubs	1
Length Through Bore	1.9375
Pulley Construction	Solid

General Specifications

UPC	662289183791
Weight	4.20 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.50.9080
Country of Origin	United States of America
