• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	28
Bore Range	1 to 2 5/16
Width (mm)	50.8 mm
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Rough Bore
Belt Section	H
Flange (in)	4.687 in
Pitch Diameter (in)	4.456 in
Outside Diameter (mm)	111.8108 mm
Outside Diameter (in)	4.402 in
Width (in)	2 in
Face Width	2.34375
Bore Diameter (in)	1 in
Pulley Construction	Solid
Number of Hubs	1
Hub Diameter (in)	3.5 in
Length Through Bore	3.40625
Overall Length (in)	3.40625 in
Hub Projection	1.0625
With Flanges	With Flanges

General Specifications

UPC	662289292738
Weight	12.08 LB
Packaged Length	6.30 IN
Packaged Width	6.40 IN
Packaged Height	4.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
