• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master6
Width (mm)	25.4 mm
Number of teeth	28
Bore Range	1/2 to 2
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Bushed Bore
Inside Diameter (in)	3.5 in
Flange (in)	4.6875 in
Pitch Diameter (in)	4.456 in
Outside Diameter (mm)	111.8108 mm
Belt Section	H
Outside Diameter (in)	4.402 in
Width (in)	1 in
Face Width	1.312
Overall Length (in)	1.70025 in
Pulley Construction	Solid
Hub Projection	0.387
Length Through Bore	1.33
With Flanges	With Flanges
Number of Hubs	1
Hub Diameter (in)	3.132 in

General Specifications

UPC	662289349050
Weight	2.98 LB
Packaged Length	5.70 IN
Packaged Width	5.30 IN
Packaged Height	2.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
