• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	3/8 to 1 1/2
Model Name	GBPulley_Master6
Number of teeth	26
Product Type	Gearbelt Pulley
Width (mm)	25.4 mm
Material	Ductile Iron
Bore Type	Bushed Bore
Pitch Diameter (in)	4.138 in
Outside Diameter (in)	4.084 in
Width (in)	1 in
Outside Diameter (mm)	103.7336 mm
Flange (in)	4.369 in
Belt Section	H
Face Width	1.312
With Flanges	With Flanges
Length Through Bore	1.276
Overall Length (in)	1.322 in
Pulley Construction	Solid

General Specifications

UPC	662289203789
Weight	3.23 LB
Packaged Length	4.90 IN
Packaged Width	4.90 IN
Packaged Height	2.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
