• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Bore Range	3/4 to 2 1/4
Number of teeth	26
Width (mm)	25.4 mm
Model Name	GBPulley_Master2
Material	Steel
Bore Type	Rough Bore
Pitch Diameter (in)	4.138 in
Outside Diameter (in)	4.084 in
Width (in)	1 in
Belt Section	H
Outside Diameter (mm)	103.7336 mm
Flange (in)	4.370 in
Face Width	1.3125
Bore Diameter (in)	0.75 in
With Flanges	With Flanges
Hub Projection	1.0625
Number of Hubs	1
Pulley Construction	Solid
Overall Length (in)	2.375 in
Hub Diameter (in)	3.375 in
Length Through Bore	2.375

General Specifications

UPC	662289314317
Weight	6.62 LB
Packaged Length	5.30 IN
Packaged Width	5.40 IN
Packaged Height	3.60 IN
HTC	8483.50.9080
Country of Origin	United States of America
