• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/2 to 2
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master6
Width (mm)	50.8 mm
Number of teeth	26
Bore Type	Bushed Bore
Material	Ductile Iron
Inside Diameter (in)	3.3125 in
Outside Diameter (mm)	105.1052 mm
Outside Diameter (in)	4.084 in
Width (in)	2 in
Belt Section	H
Flange (in)	4.370 in
Pitch Diameter (in)	4.138 in
Face Width	2.344
Pulley Construction	Solid
Hub Projection	0.325
Hub Diameter (in)	3.13 in
With Flanges	With Flanges
Number of Hubs	1
Length Through Bore	1.83
Overall Length (in)	2.669 in

General Specifications

UPC	662289348541
Weight	3.97 LB
Packaged Length	5.40 IN
Packaged Width	5.40 IN
Packaged Height	3.70 IN
HTC	8483.50.9080
Country of Origin	United States of America
