• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/4 to 11/16
Model Name	GBPulley_Master1
Number of teeth	24
Width (mm)	9.525 mm
Product Type	Gearbelt Pulley
Material	Aluminium
Bore Type	Rough Bore
Outside Diameter (mm)	38.3032 mm
Outside Diameter (in)	1.508 in
Pitch Diameter (in)	1.528 in
Belt Section	XL
Flange (in)	1.7500 in
Width (in)	0.375 in
Face Width	0.5625
Length Through Bore	0.90625
Bore Diameter (in)	0.25 in
Number of Hubs	1
Pulley Construction	Solid
Hub Projection	0.34375
Overall Length (in)	0.906 in
Hub Diameter (in)	1.0625 in
With Flanges	With Flanges

General Specifications

UPC	662289182145
Weight	0.12 LB
Packaged Length	1.70 IN
Packaged Width	2.25 IN
Packaged Height	1.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
