• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Model Name	GBPulley_Master5
Width (mm)	50.8 mm
Number of teeth	24
Bore Range	3/4 to 2 11/16
Bore Type	Bushed Bore
Material	Ductile Iron
Flange (in)	7.167 in
Outside Diameter (mm)	167.005 mm
Outside Diameter (in)	6.575 in
Inside Diameter (in)	4.9375 in
Width (in)	2 in
Belt Section	XH
Pitch Diameter (in)	6.685 in
Face Width	2.5625
With Flanges	With Flanges
Overall Length (in)	2.594 in
Length Through Bore	2.5
Pulley Construction	Solid

General Specifications

UPC	662289304325
Weight	15.42 LB
Packaged Length	8.40 IN
Packaged Width	8.30 IN
Packaged Height	3.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
