• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	5/8 to 1 3/8
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master2
Number of teeth	24
Width (mm)	19.05 mm
Material	Steel
Bore Type	Rough Bore
Belt Section	L
Width (in)	0.75 in
Pitch Diameter (in)	2.865 in
Outside Diameter (mm)	72.009 mm
Flange (in)	3.09375 in
Outside Diameter (in)	2.835 in
Face Width	1
Number of Hubs	1
Overall Length (in)	1.5 in
Bore Diameter (in)	0.625 in
Length Through Bore	1.5
Pulley Construction	Solid
With Flanges	With Flanges
Hub Projection	0.5
Hub Diameter (in)	2.25 in

General Specifications

UPC	662289232307
Weight	2.02 LB
Packaged Length	3.50 IN
Packaged Width	3.60 IN
Packaged Height	1.90 IN
HTC	8483.50.9080
Country of Origin	United States of America
