• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Number of teeth	24
Width (mm)	50.8 mm
Bore Range	3/4 to 1 3/4
Material	Ductile Iron
Bore Type	Bushed Bore
Width (in)	2 in
Pitch Diameter (in)	3.82 in
Belt Section	H
Outside Diameter (in)	3.766 in
Outside Diameter (mm)	95.6564 mm
Flange (in)	4.050 in
Face Width	2.2813
Pulley Construction	Solid
Hub Diameter (in)	3 in
With Flanges	With Flanges
Length Through Bore	3.219
Overall Length (in)	3.219 in
Number of Hubs	1
Hub Projection	0.875

General Specifications

UPC	662289314584
Weight	4.85 LB
Packaged Length	4.20 IN
Packaged Width	4.20 IN
Packaged Height	3.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
