• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	14 in
Pulley Material	Cast Iron
Number of Grooves	2
Bushing Used	SK
Model Name	23V_LG_Sheavemaster
Material	Cast Iron
Pitch Diameter (3V)	13.95
Belt Section	3V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Number of Hubs	1
Bushing Bore Range	.500 - 2.625
Overall Width (in)	1.9375
Face Width (in)	1.09375
Pulley Construction	Spoke

General Specifications

UPC	662289373161
Weight	19.82 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	1.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
