• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	50.8 mm
Number of teeth	22
Bore Range	3/4 to 2 11/16
Product Type	Gearbelt Pulley
Material	Ductile Iron
Bore Type	Bushed Bore
Width (in)	2 in
Inside Diameter (in)	4.375 in
Outside Diameter (in)	6.017 in
Belt Section	XH
Flange (in)	6.49 in
Pitch Diameter (in)	6.127 in
Outside Diameter (mm)	152.8318 mm
Face Width	2.5625
Length Through Bore	2.5
Number of Hubs	1
Overall Length (in)	3.562 in
With Flanges	With Flanges
Pulley Construction	Solid
Hub Diameter (in)	4.125 in
Hub Projection	1.00025

General Specifications

UPC	662289314638
Weight	11.75 LB
Packaged Length	8.30 IN
Packaged Width	8.10 IN
Packaged Height	3.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
