• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Bore Range	3/4 to 1 3/4
Number of teeth	22
Width (mm)	50.8 mm
Bore Type	Bushed Bore
Material	Ductile Iron
Outside Diameter (mm)	87.5538 mm
Belt Section	H
Width (in)	2 in
Outside Diameter (in)	3.447 in
Pitch Diameter (in)	3.501 in
Flange (in)	3.735 in
Face Width	2.344
Number of Hubs	1
Length Through Bore	2.938
Pulley Construction	Solid
Hub Diameter (in)	3 in
With Flanges	With Flanges
Overall Length (in)	3.129 in
Hub Projection	0.875

General Specifications

UPC	662289134113
Weight	3.01 LB
Packaged Length	4.30 IN
Packaged Width	4.30 IN
Packaged Height	3.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
