• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	3/4 to 1 3/4
Number of teeth	22
Model Name	GBPulley_Master2
Width (mm)	25.4 mm
Product Type	Gearbelt Pulley
Bore Type	Rough Bore
Material	Steel
Outside Diameter (in)	3.447 in
Width (in)	1 in
Flange (in)	3.735 in
Pitch Diameter (in)	3.501 in
Belt Section	H
Outside Diameter (mm)	87.5538 mm
Face Width	1.3125
With Flanges	With Flanges
Hub Diameter (in)	2.75 in
Pulley Construction	Solid
Overall Length (in)	2.25 in
Length Through Bore	2.25
Number of Hubs	1
Hub Projection	0.9375
Bore Diameter (in)	0.75 in

General Specifications

UPC	662289232529
Weight	4.32 LB
Packaged Length	4.20 IN
Packaged Width	4.30 IN
Packaged Height	3.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
