• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	25.4 mm
Model Name	GBPulley_Master2
Number of teeth	21
Bore Range	5/8 to 1 1/4
Product Type	Gearbelt Pulley
Bore Type	Rough Bore
Material	Steel
Pitch Diameter (in)	2.507 in
Outside Diameter (mm)	62.9158 mm
Outside Diameter (in)	2.477 in
Width (in)	1 in
Flange (in)	2.8750 in
Belt Section	L
Face Width	1.25
With Flanges	With Flanges
Number of Hubs	1
Hub Projection	0.5
Pulley Construction	Solid
Length Through Bore	1.75
Overall Length (in)	1.75 in
Hub Diameter (in)	2 in
Bore Diameter (in)	0.625 in

General Specifications

UPC	662289314287
Weight	2.39 LB
Packaged Length	3.30 IN
Packaged Width	3.00 IN
Packaged Height	2.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
