• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	25.4 mm
Bore Range	3/4 to 1 11/16
Product Type	Gearbelt Pulley
Number of teeth	21
Bore Type	Rough Bore
Material	Steel
Outside Diameter (mm)	83.5152 mm
Width (in)	1 in
Belt Section	H
Outside Diameter (in)	3.288 in
Flange (in)	3.574 in
Pitch Diameter (in)	3.342 in
Face Width	1.3125
With Flanges	With Flanges
Length Through Bore	2.125
Overall Length (in)	2.125 in
Bore Diameter (in)	0.75 in
Hub Projection	0.8125
Number of Hubs	1
Pulley Construction	Solid
Hub Diameter (in)	2.625 in

General Specifications

UPC	662289182503
Weight	3.78 LB
Packaged Length	4.20 IN
Packaged Width	4.20 IN
Packaged Height	3.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
