• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	25.4 mm
Product Type	Gearbelt Pulley
Number of teeth	20
Bore Range	1/2 to 1 1/4
Bore Type	Bushed Bore
Material	Steel
Flange (in)	2.6250 in
Outside Diameter (in)	2.357 in
Pitch Diameter (in)	2.387 in
Belt Section	L
Outside Diameter (mm)	59.8678 mm
Width (in)	1 in
Face Width	1.25
With Flanges	With Flanges
Length Through Bore	0.89
Hub Projection	0.799
Hub Diameter (in)	2 in
Pulley Construction	Solid
Number of Hubs	1
Overall Length (in)	2.049 in

General Specifications

UPC	662289346677
Weight	1.00 LB
Packaged Length	3.06 IN
Packaged Width	3.06 IN
Packaged Height	1.31 IN
HTC	8483.50.9080
Country of Origin	United States of America
