• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1 to 1 5/8
Number of teeth	20
Width (mm)	50.8 mm
Product Type	Gearbelt Pulley
Bore Type	Rough Bore
Material	Steel
Belt Section	H
Outside Diameter (mm)	79.4766 mm
Flange (in)	3.42 in
Outside Diameter (in)	3.129 in
Width (in)	2 in
Pitch Diameter (in)	3.183 in
Face Width	2.34375
Overall Length (in)	3.156 in
Number of Hubs	1
Hub Projection	0.81
Length Through Bore	3.156
Bore Diameter (in)	0.75 in
Pulley Construction	Solid
With Flanges	With Flanges
Hub Diameter (in)	2.5 in

General Specifications

UPC	662289252701
Weight	5.20 LB
Packaged Length	4.30 IN
Packaged Width	4.30 IN
Packaged Height	4.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
