• Largest selection in the Industry - Browning offers the widest range of variable speed sheaves in the market today. One and two Groove product are available in 1.6" to 8.5" covering up to 25 horsepower.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Bore (in)	0.625 in
Number of Grooves	1
Turns Open (A or 4L) (For Min PD)	5
Outside Diameter (in)	4.15 in
Turns Open (B or 5L) (For Min PD)	6
Turns Open (B or 5L) (For Max PD)	1
Type of Bore	Finished
Turns Open (3L) (For Min PD)	4
Material	Cast Iron
Pitch Diameter (B or 5L) (Min)	3.2
Pitch Diameter (3L) (Max)	3.5
Pitch Diameter (A or 4L) (Max)	4
Pitch Diameter (B or 5L) (Max)	4.2
Pitch Diameter (A or 4L) (Min)	3
Pitch Diameter (3L) (Min)	2.7
Belt Section	3L, 4L or A, 5L or B
Product Type	FHP Variable Pitch Sheaves
Keyway Size	3/16 x 3/32

General Specifications

UPC	662460590677
Weight	2.02 LB
Packaged Length	5.45 IN
Packaged Width	7.25 IN
Packaged Height	2.15 IN
HTC	8483.50.9040
Country of Origin	Mexico
