• Largest selection in the Industry - Browning offers the widest range of variable speed sheaves in the market today. One and two Groove product are available in 1.6" to 8.5" covering up to 25 horsepower.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Number of Grooves	1
Material	Cast Iron
Type of Bore	Finished
Bore (in)	0.5 in
Turns Open (3L) (For Min PD)	4
Pitch Diameter (3L) (Max)	2.4
Pitch Diameter (3L) (Min)	1.6
Belt Section	3L
Product Type	FHP Variable Pitch Sheaves
Outside Diameter (in)	2.5 in
Keyway Size	1/4 x 1/8

General Specifications

UPC	662460590592
Weight	0.96 LB
Packaged Length	7.90 IN
Packaged Width	5.45 IN
Packaged Height	2.00 IN
