• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	9.6
Outside Diameter (in)	10 in
Bushing Used	Q1
Pitch Diameter (C)	10
Material	Cast Iron
Number of Grooves	1
Pulley Material	Cast Iron
Model Name	1TC-L_Sheave_Master
Overall Length (in)	2.828125 in
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Overall Width (in)	2.78125
Face Width (in)	1.25

General Specifications

UPC	662289173365
Weight	16.38 LB
Packaged Length	10.06 IN
Packaged Width	10.06 IN
Packaged Height	1.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
