• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q1
Material	Cast Iron
Model Name	1TC-L_Sheave_Master
Number of Grooves	1
Outside Diameter (in)	8.6 in
Pitch Diameter (C)	8.6
Overall Length (in)	2.734375 in
Pulley Material	Cast Iron
Datum Diameter (C)	8.2
Belt Section	C
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500

General Specifications

UPC	662289310562
Weight	10.30 LB
Packaged Length	9.10 IN
Packaged Width	9.20 IN
Packaged Height	1.20 IN
HTC	8483.50.9040
Country of Origin	Mexico
