• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	1
Bushing Used	Q1
Datum Diameter (C)	8
Model Name	1TC-L_Sheave_Master
Pulley Material	Cast Iron
Outside Diameter (in)	8.4 in
Overall Length (in)	2.734375 in
Material	Cast Iron
Pitch Diameter (C)	8.4
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Face Width (in)	1.25
Pulley Construction	Webbed
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289310555
Weight	10.45 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	1.48 IN
HTC	8483.50.9040
Country of Origin	Mexico
