• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	11 in
Material	Cast Iron
Pulley Material	Cast Iron
Model Name	1TC-L_Sheave_Master
Bushing Used	Q1
Pitch Diameter (C)	11
Overall Length (in)	2.828125 in
Number of Grooves	1
Datum Diameter (C)	10.6
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289113538
Weight	17.70 LB
Packaged Length	11.60 IN
Packaged Width	11.60 IN
Packaged Height	2.00 IN
HTC	8483.50.9040
Country of Origin	Mexico
