• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	8.6
Pitch Diameter (A)	8.8
Model Name	1TB-L_Sheave_Master
Overall Length (in)	2.140625 in
Pulley Material	Cast Iron
Number of Grooves	1
Material	Cast Iron
Bushing Used	P1
Outside Diameter (in)	9.35 in
Pitch Diameter (B)	9.3
Datum Diameter (B)	9
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	2.1875
Pulley Construction	Spoked
Keyway Size	.375
Face Width (in)	1

General Specifications

UPC	662289172177
Weight	8.90 LB
Packaged Length	9.81 IN
Packaged Width	9.81 IN
Packaged Height	1.56 IN
