• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	1TB-L_Sheave_Master
Datum Diameter (B)	7
Pitch Diameter (B)	7.3
Material	Cast Iron
Number of Grooves	1
Bushing Used	P1
Pitch Diameter (A)	6.8
Overall Length (in)	2.140625 in
Outside Diameter (in)	7.35 in
Pulley Material	Cast Iron
Datum Diameter (A)	6.6
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.375
Face Width (in)	1
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Spoked

General Specifications

UPC	662289201976
Weight	6.75 LB
Packaged Length	8.10 IN
Packaged Width	8.20 IN
Packaged Height	1.80 IN
