• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	6
Outside Diameter (in)	6.75 in
Pulley Material	Cast Iron
Model Name	1TB-L_Sheave_Master
Pitch Diameter (A)	6.2
Overall Length (in)	2.140625 in
Material	Cast Iron
Pitch Diameter (B)	6.7
Bushing Used	P1
Datum Diameter (B)	6.4
Number of Grooves	1
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 1.750
Face Width (in)	1
Pulley Construction	Webbed
Keyway Size	.375

General Specifications

UPC	662289310340
Weight	5.92 LB
Packaged Length	7.40 IN
Packaged Width	7.60 IN
Packaged Height	1.20 IN
