• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Overall Length (in)	2.140625 in
Pitch Diameter (A)	5.6
Number of Grooves	1
Datum Diameter (A)	5.4
Pitch Diameter (B)	6.1
Datum Diameter (B)	5.8
Model Name	1TB-M_Sheave_Master
Outside Diameter (in)	6.15 in
Material	Cast Iron
Bushing Used	P1
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Keyway Size	.375
Face Width (in)	1
Overall Width (in)	2.1875
Pulley Construction	Plain
Bushing Bore Range	0.500 - 1.750

General Specifications

UPC	662289221615
Weight	5.80 LB
Packaged Length	7.60 IN
Packaged Width	7.40 IN
Packaged Height	1.20 IN
