• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	5.75 in
Number of Grooves	1
Model Name	1TB-M_Sheave_Master
Datum Diameter (A)	5
Overall Length (in)	2.140625 in
Datum Diameter (B)	5.4
Pitch Diameter (A)	5.2
Pulley Material	Cast Iron
Bushing Used	P1
Material	Cast Iron
Pitch Diameter (B)	5.7
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Face Width (in)	1
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain
Keyway Size	.375

General Specifications

UPC	662289121540
Weight	4.85 LB
Packaged Length	6.10 IN
Packaged Width	6.20 IN
Packaged Height	1.70 IN
