• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	1
Pulley Material	Cast Iron
Pitch Diameter (A)	4.8
Material	Cast Iron
Datum Diameter (A)	4.6
Bushing Used	P1
Pitch Diameter (B)	5.3
Outside Diameter (in)	5.35 in
Model Name	1TB-M_Sheave_Master
Overall Length (in)	2.140625 in
Datum Diameter (B)	5
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Face Width (in)	1
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain
Keyway Size	.375

General Specifications

UPC	662289310289
Weight	3.98 LB
Packaged Length	5.70 IN
Packaged Width	5.80 IN
Packaged Height	1.10 IN
