• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Number of Grooves	1
Model Name	1TB-S_Sheave_Master
Pulley Material	Cast Iron
Bushing Used	P1
Overall Length (in)	2.265625 in
Outside Diameter (in)	4.15 in
Pitch Diameter (A)	3.6
Pitch Diameter (B)	4.1
Datum Diameter (B)	3.8
Datum Diameter (A)	3.4
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Face Width (in)	1
Keyway Size	.375
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain
Overall Width (in)	2.3125

General Specifications

UPC	662289231171
Weight	2.67 LB
Packaged Length	4.70 IN
Packaged Width	4.70 IN
Packaged Height	1.60 IN
