• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q1
Model Name	1TB-L_Sheave_Master
Overall Length (in)	2.828125 in
Material	Cast Iron
Number of Grooves	1
Pulley Material	Cast Iron
Outside Diameter (in)	15.75 in
Pitch Diameter (A)	15.2
Pitch Diameter (B)	15.7
Datum Diameter (B)	15.4
Datum Diameter (A)	15
Bore (Min) (in)	0.75 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Keyway Size	0.5
Overall Width (in)	2.79
Pulley Construction	Spoke
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1

General Specifications

UPC	662289232369
Weight	24.00 LB
Packaged Length	16.10 IN
Packaged Width	15.90 IN
Packaged Height	2.00 IN
