• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Model Name	1TB-L_Sheave_Master
Outside Diameter (in)	13.88 in
Datum Diameter (A)	13.2
Pitch Diameter (A)	13.4
Datum Diameter (B)	13.6
Overall Length (in)	2.828125 in
Number of Grooves	1
Bushing Used	Q1
Pitch Diameter (B)	13.9
Pulley Material	Cast Iron
Belt Section	A, B
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Face Width (in)	1
Overall Width (in)	2.78125
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289242375
Weight	18.77 LB
Packaged Length	14.60 IN
Packaged Width	14.50 IN
Packaged Height	2.20 IN
