• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Number of Grooves	1
Pitch Diameter (3V)	6.85
Material	Cast Iron
Bushing Used	P1
Overall Length (in)	2.140625 in
Outside Diameter (in)	6.9 in
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	3V
Bore Type	Split Taper Bushed
Bushing Bore Range	0.500 - 1.750
Keyway Size	.375
Face Width (in)	0.6875
Overall Width (in)	2.1875
Pulley Construction	Spoked

General Specifications

UPC	662289169955
Weight	5.11 LB
Packaged Length	7.40 IN
Packaged Width	7.50 IN
Packaged Height	1.40 IN
