• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (3V)	5.25
Pulley Material	Cast Iron
Bushing Used	P1
Overall Length (in)	2.140625 in
Outside Diameter (in)	5.3 in
Number of Grooves	1
Material	Cast Iron
Belt Section	3V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Overall Width (in)	2.1875
Face Width (in)	0.6875
Bushing Bore Range	0.500 - 1.750
Keyway Size	.375

General Specifications

UPC	662289119684
Weight	5.44 LB
Packaged Length	5.70 IN
Packaged Width	5.60 IN
Packaged Height	1.50 IN
HTC	8483.50.9040
Country of Origin	Mexico
