• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Hubs	1
Bushing Used	H
Belt Type	Classic or 358
Number of Flanges	2
Material	Cast Iron
Pulley Material	Cast Iron
Number of Grooves	1
Pitch Diameter (3V)	5.95
Outside Diameter (in)	6 in
Overall Length (in)	1.5 in
Bore (Min) (in)	0.375 in
Belt Section	3V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	0.6875
Bushing Bore Range	.375 - 1.500
Pulley Construction	Spoke
Overall Width (in)	1.5

General Specifications

UPC	662289159819
Weight	3.18 LB
Packaged Length	7.31 IN
Packaged Width	7.31 IN
Packaged Height	1.13 IN
