• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Bushing Used	H
Number of Grooves	1
Overall Length (in)	1.3125 in
Pulley Material	Cast Iron
Outside Diameter (in)	3.35 in
Pitch Diameter (3V)	3.3
Belt Section	3V
Bore (Min) (in)	0.375 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	0.375 - 1.500
Pulley Construction	Plain
Overall Width (in)	1.4375
Face Width (in)	0.6875

General Specifications

UPC	662289238897
Weight	1.04 LB
Packaged Length	3.56 IN
Packaged Width	3.56 IN
Packaged Height	1.44 IN
