• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	1
Material	Cast Iron
Datum Diameter (C)	5.6
Pulley Material	Cast Iron
Overall Length (in)	2.140625 in
Bushing Used	P1
Outside Diameter (in)	6 in
Pitch Diameter (C)	6
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	Split Taper Bushed
Bushing Bore Range	0.500 - 1.750
Keyway Size	.375
Pulley Construction	Plain
Overall Width (in)	2.1875
Face Width (in)	1.25

General Specifications

UPC	662289311101
Weight	6.15 LB
Packaged Length	6.06 IN
Packaged Width	6.06 IN
Packaged Height	1.56 IN
