• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (A)	8.8
Number of Grooves	1
Material	Cast Iron
Datum Diameter (A)	8.6
Pulley Material	Cast Iron
Pitch Diameter (5V)	9.1
Model Name	1B5V-SheaveMaster
Bushing Used	B
Datum Diameter (B)	9
Pitch Diameter (B)	9.3
Outside Diameter (in)	9.28 in
Overall Length (in)	2.3125 in
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	1
Pulley Construction	Spoked
Bushing Bore Range	0.500 - 2.4375
Keyway Size	.500
Overall Width (in)	2.3125

General Specifications

UPC	662289034215
Weight	9.84 LB
Packaged Length	10.00 IN
Packaged Width	10.00 IN
Packaged Height	2.10 IN
