• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pulley Material	Cast Iron
Datum Diameter (B)	6.8
Material	Cast Iron
Number of Grooves	1
Overall Length (in)	2.140625 in
Datum Diameter (A)	6.4
Pitch Diameter (5V)	6.9
Bushing Used	B
Model Name	1B5V-SheaveMaster
Outside Diameter (in)	7.08 in
Pitch Diameter (B)	7.1
Pitch Diameter (A)	6.6
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 2.4375
Face Width (in)	1
Pulley Construction	Webbed
Keyway Size	.500

General Specifications

UPC	662289034116
Weight	6.39 LB
Packaged Length	7.40 IN
Packaged Width	7.70 IN
Packaged Height	1.20 IN
