• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Datum Diameter (B)	5
Pulley Material	Cast Iron
Pitch Diameter (B)	5.3
Material	Cast Iron
Number of Grooves	1
Overall Length (in)	2.140625 in
Outside Diameter (in)	5.28 in
Bushing Used	B
Pitch Diameter (5V)	5.1
Pitch Diameter (A)	4.8
Datum Diameter (A)	4.6
Model Name	1B5V-SheaveMaster
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	2.1875
Face Width (in)	1
Bushing Bore Range	0.500 - 2.4375
Pulley Construction	Plain
Keyway Size	.500

General Specifications

UPC	662289033775
Weight	3.28 LB
Packaged Length	5.60 IN
Packaged Width	5.60 IN
Packaged Height	1.40 IN
