• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Datum Diameter (B)	20
Outside Diameter (in)	20.28 in
Pulley Material	Cast Iron
Number of Hubs	1
Number of Grooves	1
Bushing Used	B
Model Name	1B5V-SheaveMaster
Datum Diameter (A)	19.6
Number of Flanges	2
Belt Type	Classic or 358
Pitch Diameter (5V)	20.1
Overall Length (in)	2.3125 in
Material	Cast Iron
Pitch Diameter (A)	19.8
Pitch Diameter (B)	20.3
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Pulley Construction	Spoke
Face Width (in)	1
Bushing Bore Range	.500 - 2.4375
Overall Width (in)	2.2
Keyway Size	0.5

General Specifications

UPC	662289033669
Weight	23.04 LB
Packaged Length	20.38 IN
Packaged Width	20.38 IN
Packaged Height	2.00 IN
