• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Bushing Used	B
Outside Diameter (in)	12.68 in
Datum Diameter (B)	12.4
Number of Grooves	1
Pitch Diameter (A)	12.2
Material	Cast Iron
Pitch Diameter (B)	12.7
Pulley Material	Cast Iron
Pitch Diameter (5V)	12.5
Model Name	1B5V-SheaveMaster
Overall Length (in)	2.3125 in
Datum Diameter (A)	12
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Keyway Size	0.500
Pulley Construction	Spoke
Bushing Bore Range	0.500 - 2.4375
Face Width (in)	1
Overall Width (in)	2.2

General Specifications

UPC	662289033577
Weight	15.38 LB
Packaged Length	13.40 IN
Packaged Width	13.20 IN
Packaged Height	1.80 IN
