• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pulley Material	Cast Iron
Model Name	1B5V-SheaveMaster
Outside Diameter (in)	11.28 in
Pitch Diameter (5V)	11.1
Datum Diameter (B)	11
Pitch Diameter (A)	10.8
Material	Cast Iron
Datum Diameter (A)	10.6
Number of Grooves	1
Bushing Used	B
Overall Length (in)	2.3125 in
Pitch Diameter (B)	11.3
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Number of Hubs	1
Bore Type	Split Taper Bushed
Face Width (in)	1
Overall Width (in)	2.22
Keyway Size	0.500
Pulley Construction	Spoke
Bushing Bore Range	0.500 - 2.4375

General Specifications

UPC	662289033539
Weight	12.00 LB
Packaged Length	11.38 IN
Packaged Width	11.38 IN
Packaged Height	1.75 IN
