• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	1
Pitch Diameter (B)	5.1
Model Name	1AB_LG_Sheavemaster
Bushing Used	SDS
Material	Cast Iron
Datum Diameter (B)	4.8
Datum Diameter (A)	4.4
Pulley Material	Cast Iron
Pitch Diameter (A)	4.6
Outside Diameter (in)	5.15 in
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000

General Specifications

UPC	662289332649
Weight	3.05 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
